VSX-415-K
52
1234
1234
C
D
F
A
B
E
5. ELECTRICAL PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω
RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..MAIN ASSY XWK3177
1..DSP ASSY AWX8418
NSP 1..AMP & PS ASSY XWK3133
2..AMP & PRIMARY ASSY XWZ3783
2..TRANS2 ASSY XWZ3810
2..TRANS3 ASSY XWZ3813
2..REGULATOR ASSY XWZ3825
2..AMP INPUT ASSY XWZ3802
2..TRANS1 ASSY XWZ3806
NSP 1..COMPLEX ASSY XWK3166
2..VIDEO ASSY XWZ3903
2..5.1CH ASSY XWZ3914
2..FRONT DISPLAY ASSY XWZ3908
2..R.ENCODER ASSY XWZ3920
2..POWER SW & KEY ASSY XWZ3917
2..FRONT KEY ASSY XWZ3912
2..H.P. ASSY XWZ3923
1..FM/AM TUNER UNIT AXX7170
Mark No. Description Part No.
AMP & PS ASSY
OTHERS
J21 JUMPER WIRE D20PYY0715E
COMPLEX ASSY
OTHERS
J41 JUMPER WIRE 4P D20PYY0411E
J42 6P JUMPER WIRE D20PYY0608E
J47 JUMPER WIRE 6P D20PYY0630E
J40 JUMPER WIRE 7P D20PYY0907E
A
MAIN ASSY
SEMICONDUCTORS
IC108 BD3813KS
IC101 BD3841FS
IC5001 BU1924F
IC103-IC105, IC107 HA17558AF
IC102 NJM2100M
IC9001 PD5963C
IC110-IC112 UPC4570G2
Q5004 2SA1037K
Q5009 2SC2412K
Q165, Q166, Q321, Q322 2SC3326
Q341, Q342, Q361, Q362, Q395 2SC3326
Q5001 2SD1664
Q229, Q230 2SK208
Q167, Q231, Q9002-Q9005 DTA124EK
Q9008 DTA143TK
Q232 DTC124EK
Q168, Q5003, Q9001 DTC143EK
Q9007 DTC143TK
D103-D108, D229, D230, D301 1SS355
D311, D312, D9001-D9013 1SS355
D101, D102 RB501V-40
D5007 UDZS10B
D331, D332 UDZS6.8B
COILS AND FILTERS
L9001, L9002 Chip Solid Inductor ATL7002
L5001, L9003 LFEA2R2J
L101-L104, L111, L112, L5002 QTL1013
Chip Solid Inductor
CAPACITORS
C9003 (0.22F/5.6V) ACH7144
C101-C114, C151, C152 CCSRCH101J50
C163, C164, C183-C192 CCSRCH101J50
C243, C244, C263, C317, C318 CCSRCH101J50
C323, C324, C343, C344, C363 CCSRCH101J50
C1031, C1041, C117, C118 CCSRCH220J50
C5013, C5014 CCSRCH270J50
C205-C208, C245-C248, C265 CCSRCH331J50
C267 CCSRCH331J50
C203, C204 CCSRCH471J50
C5017 CCSRCH561J50
C366 CEANP4R7M50
C123-C128, C131-C138 CEAT100M50
C141, C142, C167, C168 CEAT100M50
C209, C210, C213, C214 CEAT100M50
C249, C250, C269, C270 CEAT100M50
C301-C306, C321, C322 CEAT100M50
C341, C342, C361, C362 CEAT100M50
C5015 CEAT101M10
C5007 CEAT101M16
C169 CEAT221M6R3
C201, C202, C241, C242 CEAT2R2M50
C261, C262, C5011, C9005 CEAT2R2M50
C9007 CEAT331M6R3
C325, C326, C345, C346, C365 CEAT470M25
C155, C156 CEAT470M50
Mark No. Description Part No.
To Next Page
