Pioneer XC-LA21 - Page 32

32
XC-LA21
Mark No. Description Part No.
Mark No. Description Part No.
OTHERS
CONN PIN 3 PINS 050-030160-200J
J201 CONN PIN 14 PINS 050-140060-200J
GND JP WIRE AWG22 140MM 051-275140-009J
J904 RCA JACK HSP-244V-01 118-000244-000A
J903 RCA JACK,HSP-202V-01 118-020202-000A
J905 POWER JACK DC 120-100470-000
CN204 HSG CD189D-3A 136-03189D-200J
RECT ASSY
CAPACITORS
IC301 (IC REGULA BA09ST) 010-400009-001A
IC302 NJM78M56FA
Q302, Q303 (TRLPNPPWR 3CA8550) 008-685500-000A
Q305, Q301 DTC114ES
D301-D304 011-020005-000A
D305 (ZENER IN-5237B,8.2V) 011-010082-120A
D307, D306, D310, D309, D313 011-024001-000A
(RECTIFIER IN-4001B)
D308 (ZENER BZX55C24 24V) 011-010240-120A
CAPACITORS
C301, C317 CEAT221M16
C302 CEAT222M25
C303–C306, C308, C309 CKCYF103Z50
C307 CEAT101M35
C310 CEAT101M50
C318 CEAT102M16
RESISTORS
R304 RS1/2LMF221J
Other Resistors RD1/4PU J
OTHERS
P301 JP WIRE AWB22#1007 051-275120-009J
JP WIRE AWG26#1007 051-675300-010J
CN204 HSG PMT1-9A 136-09PMT1-C00J
CN301 HEADER 14 PINS 135-2001WS-140J
CN302 CONN PIN 12 PINS 050-120060-251J
TRANS ASSY
SEMICONDUCTORS
F304, F305, F307 124-010010-002A
(IC MICRO FUSE 251001 1A)
F303 124-035010-000A
(IC MICRO FUSE #25103.5-TS2 3.5A)
D311 (RECTIFIER IN-4001B) 011-024001-000A
COIL
L301 AC LINE FILTER 019-500160-000A
SWITCHES AND RELAYS
SW301, SW302 025-230041-000A
SLIDE SW (VOLT.SELECTOR 117-220V)
RL301 (RELAY 9V SDT-S-109LMR) 128-090109-000A
CAPACITORS
C315, C316 003-010320-250A
(CERAMIC CAP 0.01 uF/250V)
OTHERS
JP WIRE AWG22#UL1672 051-265160-003J
JP WIRE AWG22 YELLOW 051-265180-010J
AC CONTACT TERMINAL 137-400001-000J
F306 FUSE HOLDER 7900 550-790000-000J
DISPLAY/CTL ASSY
SEMICONDUCTORS
IC401 PDA068A
Q402–Q405 DTC114ES
Q406 2SC1815
D402, D403, D401, D404 1N4148
LED401-LED403 (LED-Y-3MM) 110-033045-013A
LED412 (LED-R-3MM) 110-033040-013A
LED404–LED411 (LED-BL-3MM) 110-033162-003A
SWITCHES
S401–S404, S408–S415 021-114165-000A
SW405–SW407 021-114165-000A
(F021-KHH902-001) TACT SW
CAPACITORS
C401, C403, C497, C498, C499 CKCYF103Z50
C412, C413, C421, C410, C411, C500 CKCYF103Z50
C402, C404 CEAT1R0M50
C405, C495 CGCYX104M16
C406 CEAT100M50
C407 (ELECT CAP 47000MFD/5.5V) 006-747300-05CA
C414 CEAT220M25
C415, C409, C422 CKCYF473Z50
C416, C417 CCCCH220J50
C419, C418 (CERAMIC CAP 30pF/50V) 003-430050-050
C420, C408 CEAT101M10
RESISTORS
RA404-RA406 001-220104-000A
(RESISTOR NETWORK100K)
RA403 (RESISTOR NETWORK EXB) 001-229103-000A
VR401,VR402 (ROTARY ENCORDER) 030-H12203-204A
Other Resistors RD1/4PU J
OTHERS
CN15 CONN PIN 10 PINS 050-100050-201J
JP WIRE AWB22#1007 051-275120-009J
REM401 111-000638-000A
(REMOTE/CONTROL PHOTO RECEIVER)
LCD401 VACUUM FLUORESCENT 115-000920-000A
CN401 FFC CONN SOCKET 24P 135-FESTVK-240J
CN404 FFC CONN SOCKET 17P 135-TOCB17-171J
X401 CRYSTAL RESONATOR 009-332768-100A
(32.768kHz)
X402 CERAMIC RESONATOR 020-000800-000A
(8MHz)
