Pioneer XC-LA21 - Adjustment Procedures; CD Section Adjustment Steps; Required Jigs and Instruments

33
XC-LA21
CD TEST DISC
(YEDS-7)
Precise
screwdriver
screwdriver
(small)
screwdriver
(medium)
screwdriver
(large)
Dual-trace
oscilloscope
(10 : 1 probe)
(1) Jigs and Measuring Instruments
(2) Necessary Adjustment Points
6.1 CD SECTION
6.1.1 PREPARATIONS
CD ASSY is taken out according to the procedure of DISASSEMBLY. And, please adjust the part CD after connecting connectors.
When
Exchange
PICKUP
1, 2, 3, 4
1, 2, 3, 4
1, 2, 3, 4
Exchange
CD ASSY
Exchange
SERVO MECH ASSY
Adjustment Points
Pages 35 and 36
Pages 35 and 36
Pages 35 and 36
6. ADJUSTMENT
