91
XR-A9800D
Remove a Bonnet (Eleven screws).
and remove the $M Mecha DVD (5P).
1
DIAGNOSIS of AF and REAR AMP ASSYS
Rear Panel
FM/AM TUNER Module
Please be useless in this case
and remove FM/AM TUNER Module.
AF Assy
REAR AMP Assy
3
44
4
55
Diagnosis
The product operates even if $M DVD Mecha. is not connected.
Put the Insulation Sheet
2
× 3
2
× 4
2
2
× 2
2
× 2
5
× 3
2
2
