Pioneer XR-VS500D User Manual

XR-VS500D, XR-VS300D
4
XR-VS300D/DBXJ, DDXJ/RA, DDXJ/RB, DLXJ/NC and XR-A9800D/KUCXJ are constructed the same except for
the following :
CONTRAST TABLE for XR-VS300D
Part No.
Ref. No. Mark Symbol and Description
XR-A9800D XR-VS300D XR-VS300DXR-VS300D XR-VS300D Remarks
/KUCXJ /DBXJ /DDXJ/RA /DDXJ/RB /DLXJ/NC
PCB ASSEMBLIES
MAIN ASSY XWM3174 XWM3171 XWM3171 XWM3171 XWM3171
P5- 1 AF ASSY XWZ3330 XWZ3316 XWZ3316 XWZ3316 XWZ3316
P5- 2 SECONDARY ASSY XWZ3323 XWZ3317 XWZ3317 XWZ3317 XWZ3317
COMPLEX ASSY XWM3178 XWM3175 XWM3175 XWM3175 XWM3175
P5- 3 REAR AMP ASSY XWZ3325 XWZ3319 XWZ3319 XWZ3319 XWZ3319
P5- 4 PRIMARY ASSY XWZ3332 XWZ3320 XWZ3320 XWZ3320 XWZ3320
P7- 1 DISPLAY ASSY XWZ3331 XWZ3318 XWZ3318 XWZ3318 XWZ3318
PACKING SECTION
P3- 1 Power Cord ADG7022 ADG1158 ADG1158 ADG1158 ADG1154
P3- 5 Remote Control Unit XZN3109 XZN3108 XZN3108 XZN3108 XZN3108
P3-11 Packing Case XHD3144 XHD3135 XHD3135 XHD3135 XHD3136
P3-12 NSP Warranty Card ARY7045 Not used Not used Not used Not used
P3-14 Operating Instructions XRE3036 Not used Not used Not used Not used
(English/French)
Operating Instructions Not used XRE3035 XRE3035 XRE3035 XRE3035
(English/Chinese)
Operating Instructions Not used Not used XRC3022 XRC3022 Not used
(Spanish/Arabian)
Region Label Not used Not used VRW1708 VRW1701 Not used For Packing Case
Caution Sheet Not used Not used XRH3001 Not used Not used Accessories
EXTERIOR SECTION
P5-12
Power Transformer (T1) (AC120V) XTS3042 Not used Not used Not used Not used
P5-12
Power Transformer (T1) Not used XTS3039 XTS3039 XTS3039 XTS3039
(AC110-127V/220-230V/240V)
P5-13
Fuse (FU1 : 6.3A) REK1085 Not used Not used Not used Not used
P5-13
Fuse (FU1 : T5A) Not used AEK1061 AEK1061 AEK1061 AEK1061
P5-15 Power Bracket XNG3033 Not used Not used Not used Not used
P5-25 Rear Panel XNC3065 XNC3063 XNC3063 XNC3063 XNC3064
P5-26 SEC Holder XMR3032 XMR3033 XMR3033 XMR3033 XMR3033
P5-41 NSP Fuse Card AAX2374 Not used Not used Not used Not used
P5-42 NSP Getter XAX3175 XAX3174 XAX3174 XAX3174 XAX3174
P5-43 65 Label ARW7050 Not used Not used Not used Not used
P5-44 NSP $M Mecha. DVD (5p) XXA3019 Not used Not used Not used Not used
P5-44 NSP $M Mecha. DVD (2p) Not used XXA3018 XXA3018 XXA3018 XXA3018
Fuse (FU2, FU3 : T3.15A) Not used AEK1059 AEK1059 AEK1059 AEK1059 *1
NSP Name Label Not used Not used XAL3049 XAL3049 Not used *2
NSP Region Label Not used Not used XAX3183 XAX3184 Not used For Rear Panel
Caution Label Not used Not used Not used Not used PRW1018 *3
NSP SISIR Label Not used Not used Not used Not used XAX3181 For Rear Panel
FRONT PANEL SECTION
P7-26 Display Panel XAK3135 XAK3134 XAK3134 XAK3134 XAK3134
P7-33 FL Cover XAK3164 XAK3163 XAK3163 XAK3163 XAK3163
P7-42 Sub Panel S XAK3203 XAK3202 XAK3202 XAK3202 XAK3202
P7-50 DV Button L XAD3057 XAD3058 XAD3058 XAD3058 XAD3058
Mic Knob Not used XAB3007 XAB3007 XAB3007 XAB3007 No. 1
Notes : For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES” and “3. SCHEMATIC DIAGRAM”.
The numbers in the remarks column correspond to the numbers on the “ EXPLODED VIEWS ”.
*1 Refer to “3. SCHEMATIC DIAGRAM”.
*2 Stick Name Label on the Rear Panel.
*3 Refer to “LABEL CHECK”.

Pioneer XR-VS500D Specifications

General

Brand	Pioneer
Model	XR-VS500D
Category	Stereo Receiver
Language	English
