XR-VS500D, XR-VS300D
8
XWZ3324, XWZ3318 and XWZ3331 are constructed the same except for the following :
DISPLAY ASSY
F
M
Mark Symbol and Description
Part No.
Remarks
XWZ3331 XWZ3324 XWZ3318
IC3931 Not used M65855FP M65855FP
IC5601 HEF4794BT HEF4794BT Not used
Q5822–Q5824, Q5827 Not used Not used DTC143EK
D3931 Not used MTZJ5.1B MTZJ5.1B
D5592 1SS133 Not used Not used
D5593 1SS133 1SS133 Not used
D5595 1SS181 1SS181 Not used
L3921, L3922 CHIP BEAD VTL1081 VTL1081 Not used
L3931 Not used LCTB100K2125 LCTB100K2125
C3931, C3934, C3940 Not used CKSRYB103K50 CKSRYB103K50
C3932 Not used CEJAR47M50 CEJAR47M50
C3933 Not used CEJQ220M10 CEJQ220M10
C3935 Not used CKSRYB473K16 CKSRYB473K16
C3937 Not used CEJA4R7M50 CEJA4R7M50
C3938 Not used CKSRYB472K50 CKSRYB472K50
C3939 Not used CKSRYB123K50 CKSRYB123K50
C3942 Not used CKSRYF104Z25 CKSRYF104Z25
C3943 Not used CEJQ101M10 CEJQ101M10
C5601 CCSRCH101J50 CCSRCH101J50 Not used
C5603, C5604 CCSRCH100D50 CCSRCH100D50 Not used
R3931 Not used RS1/16S472J RS1/16S472J
R3932, R3937, R3938 Not used RS1/16S123J RS1/16S123J
R3933 Not used RS1/16S153J RS1/16S153J
R3934 Not used RS1/16S124J RS1/16S124J
R3935 Not used RS1/16S822J RS1/16S822J
R3936 Not used RS1/16S103J RS1/16S103J
R3939 RS1/16S0R0J Not used Not used
R3940 Not used RD1/4PU121J RD1/4PU121J
R5590, R5984, R5985, R5987, R5990 RS1/16S473J RS1/16S473J Not used
R5591 RS1/16S152J RS1/16S152J Not used
R5610 Not used Not used RS1/16S0R0J
R5619 RS1/16S221J RS1/16S221J Not used
R5620, R5621, R5626 RS1/16S102J RS1/16S102J Not used
R5986, R5988, R5989 RS1/16S103J RS1/16S103J Not used
VR3931 (10kΩ-B) Not used XCS3002 XCS3002
CN5502 FFC CONNECTOR 21P 52492-2120 52492-2120 Not used
CN5502 FFC CONNECTOR 7P Not used Not used 52492-0720
Mark Symbol and Description
Part No.
Remarks
XWZ3332 XWZ3326 XWZ3320
S1 VOLTAGE SELECTOR Not used XKX3001 XKX3001
R1 (2.2MΩ/ 1/2W) RCN1080 Not used Not used
AN1 1P AC INLET XKP3042 XKP3041 XKP3041
CN2 4P VH CONNECTOR Not used B4P7-VH B4P7-VH
H3–H6 FUSE CLIP Not used AKR7001 AKR7001
PRIMARY ASSY
F
L
XWZ3326, XWZ3320 and XWZ3332 are constructed the same except for the following :
To Next Page
