XR-VS500D, XR-VS300D
7
REAR AMP ASSY
F
K
XWZ3319 and XWZ3325 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3325 XWZ3319
IC3401 STK402-230 Not used
Q3401–Q3404 2SD2114K Not used
Q3405, Q3410 DTA124EK Not used
Q3406–Q3409, Q3411–Q3413, Q3415 2SC2412K Not used
Q3414, Q3471, Q3472 2SA1037K Not used
D50, D3425, D3426, D3471, D3472 1SS355 Not used
D61, D62, D3403–D3408, D3427, D3428 1SS133 Not used
D3409 MTZJ12C Not used
D3429 MTZJ4.7B Not used
L3401–L3403 AF CHOKE COIL ATH-133 Not used
L3404 CHIP BEAD VTL1081 Not used
RY3401, RY3402 ASR7017 Not used
C3401–C3403 CEANP2R2M50 Not used
C3404–C3406 CKSRYB222K50 Not used
C3407–C3409 CCSRCH221J50 Not used
C3410–C3412 CEANP100M35 Not used
C3413–C3415 CCSRCJ3R0C50 Not used
C3416, C3417, C3431 CEAT101M50 Not used
C3419 CEATR47M50 Not used
C3420 CEAT101M10 Not used
C3421 CEAT100M50 Not used
C3422, C3471, C3472 CCSRCH100D50 Not used
C3423, C3424, C3429 CKSRYB103K50 Not used
C3425–C3428 CKSRYF104Z25 Not used
C3432 CEAT221M16 Not used
R3401–R3404 RS1/16S332J Not used
R3405–R3408 RS1/16S102J Not used
R3409–R3411 RS1/10S273J Not used
R3412 RS1/10S104J Not used
R3413–R3415 RS1/16S563J Not used
R3416–R3418 RS1/10S561J Not used
R3419–R3421 RD1/4PU563J Not used
R3422 RS1/10S223J Not used
R3424 RS1/16S102J Not used
R3425–R3428 RS1/10S823J Not used
R3429, R3430, R3432 RS1/10S153J Not used
R3433 RS1/16S273J Not used
R3434, R3475, R3476 RS1/10S392J Not used
R3435 RS1/16S104J Not used
R3436–R3437, R3439, R3440 RS1/16S223J Not used
R3438 RS1/16S103J Not used
R3441 RS1/16S224J Not used
R3442–R3444 RD1/4LMF100J Not used
R3445–R3447 RS1/16S100J Not used
R3448 RS3LMF102J Not used
R3449 RD1/4PU681J Not used
R3471–R3473 RS1LMFR22J Not used
R3477–R3478 RD1/4MUF101J Not used
CN3401 1P PIN JACK AKB7042 Not used
CN3404 FFC CONNECTOR 25P HLEM25R-1 Not used
CN3404 FFC CONNECTOR 15P Not used HLEM15R-1
J3401 JUMPER WIRE D15A09-100-2651 Not used
JA3403 AUDIO 3P PIN JACK XKB3007 Not used
9P CABLE HOLDER 51063-0905 Not used
