XR-VS500D, XR-VS300D
6
AF ASSY
F
I
XWZ3322, XWZ3316 and XWZ3330 are constructed the same except for the following :
Mark Symbol and Description
Part No.
Remarks
XWZ3330 XWZ3322 XWZ3316
IC3301 STK407-070B STK407-070B STK407-090B
IC3305, IC3306 (5A) AEK7019 AEK7019 Not used
IC3305, IC3306 (7A) Not used Not used AEK7021
IC3835 Not used M65847AFP M65847AFP
Q3351 IRFI9Z34G IRFI9Z34G IRF9540A
Q3352 IRFIZ34G IRFIZ34G IRF540A
Q3803 Not used 2SD1858X 2SD1858X
D3002 1SS133 1SS133 Not used
D3803 Not used MTZJ5.6B MTZJ5.6B
F2201, F2202 RTF1209 XTF3002 XTF3002
L3065 CHIP BEAD VTL1081 VTL1081 Not used
L3065 Not used Not used LCTB4R7K1608
C3011, C3012 Not used Not used CEAT100M50
C3042, C3991 CKSRYB103K50 CKSRYB103K50 Not used
C3623, C3624 CKSRYB471K50 CKSRYB471K50 Not used
C3625 CEAT330M16 CEAT330M16 Not used
C3815 Not used CEAT100M50 CEAT100M50
C3816, C3819 Not used CEAT470M16 CEAT470M16
C3817 Not used CCSRYB473K16 CCSRYB473K16
C3818 Not used CCSRCH101J50 CCSRCH101J50
C3828–C3830 Not used CKSRYB683K16 CKSRYB683K16
C3831 Not used CKSRYB102K50 CKSRYB102K50
C3832 Not used CKSRYB122K50 CKSRYB122K50
C3833–C3836 Not used CKSRYB103K50 CKSRYB103K50
C3837 Not used CCSRCH471J50 CCSRCH471J50
C3838 Not used CKSRYB472K50 CKSRYB472K50
C3839, C3840 Not used CKSRYB224K10 CKSRYB224K10
C3842, C3843 Not used CEAT2R2M50 CEAT2R2M50
C3858 CEAT100M50 Not used Not used
C3890 Not used CKSRYB822K50 CKSRYB822K50
R3010 RS1/16S822J RS1/16S822J RS1/16S472J
R3026 RD1/4PU822J RS1/4PU822J RD1/4PU472J
R3627 RS1/16S471J RS1/16S471J Not used
R3831 Not used RS1/4PU102J RD1/4PU102J
R3832–R3834 Not used RS1/16S102J RS1/16S102J
R3835, R3839 Not used RS1/16S682J RS1/16S682J
R3836, R3837 Not used RS1/16S472J RS1/16S472J
R3838, R3846 Not used RS1/16S153J RS1/16S153J
R3840–R3842, R3844, R3845 Not used RS1/16S103J RS1/16S103J
R3843 Not used RS1/16S562J RS1/16S562J
R3855 Not used RS1/16S680J RS1/16S680J
CN3601 4P SPEAKER TERMINAL AKE7018 XKE3004 XKE3004
CN3603 9P JUMPER CONNECTOR KPE9 KPE9 Not used
CN5104 30P FFC CONNECTOR HLEM30R-1 HLEM30R-1 Not used
CN5104 16P FFC CONNECTOR Not used Not used HLEM16R-1
JA3441 2P PIN JACK Not used Not used VKB1060
JA3991 HEADPHONE JACK XKN3007 XKN3007 XKN3004
SCREW Not used Not used BBZ30P140FMC
MICA SHEET Not used Not used XEE3003
FET BRACKET Not used Not used XNG3016
