SECTION 7
PA-28-181, ARCHER III DESCRIPTION & OPERATION
ISSUED: JULY 12, 1995 REPORT: VB-1611
7-15
SECTION 7
PA-28-181, ARCHER III DESCRIPTION & OPERATION
ISSUED: JULY 12, 1995 REPORT: VB-1611
7-15
1. CLOCK
2. AIRSPEED INDICATOR
3. ATTITUDE GYRO
4. ALTIMETER
5. DAY/NIGHT SWITCH
6. ANNUNCIATOR PANEL (with Press to Test)
7. COMPASS (MAGNETIC)
7a. COMPASS CORRECTION CARD
8. COMM / NAV RADIO
9. TRANSPONDER
10 AMMETER (DIGITAL)
11. HOUR METER
12. TACHOMETER (RPM)
13. FUEL QUANTITY
14. DIRECTIONAL GYRO
15. TURN & BANK
16. VACUUM GAUGE or Optional EGT (Exhaust Gas
Temperature Gauge) when Garmin G500 installed.
17. CABIN AIR CONTROL
WINDSHIELD DEFROST AND HEAT
18. CIRCUIT BREAKER PANEL
19. CARB. HEAT
20. SWITCH PANEL (Avionics - Pitot Heat)
21. ENGINE GAUGE, OIL TEMP
OIL AND FUEL PRESSURE, .
22. VOR/LOC NAVIGATION INDICATOR
23. VERTICAL SPEED INDICATOR
24. LIGHT CONTROL AND DIMMING
SWITCH, INST.PANEL,& RADIOS
25. OPTIONAL EGT (Exhaust Gas Temprature
Gauge) when Standard Instrument Package
installed.
26. MIC/PHONE JACKS
27. ELT CONTROL
28. INTERCOM CONTROL
29 CIGAR LIGHTER
Typical VFR Panel
REVISED: FEBRUARY 5, 2010
REVISED: FEBRUARY 5, 2010
1. CLOCK
2. AIRSPEED INDICATOR
3. ATTITUDE GYRO
4. ALTIMETER
5. DAY/NIGHT SWITCH
6. ANNUNCIATOR PANEL (with Press to Test)
7. COMPASS (MAGNETIC)
7a. COMPASS CORRECTION CARD
8. COMM / NAV RADIO
9. TRANSPONDER
10 AMMETER (DIGITAL)
11. HOUR METER
12. TACHOMETER (RPM)
13. FUEL QUANTITY
14. DIRECTIONAL GYRO
15. TURN & BANK
16. VACUUM GAUGE or Optional EGT (Exhaust Gas
Temperature Gauge) when Garmin G500 installed.
17. CABIN AIR CONTROL
WINDSHIELD DEFROST AND HEAT
18. CIRCUIT BREAKER PANEL
19. CARB. HEAT
20. SWITCH PANEL (Avionics - Pitot Heat)
21. ENGINE GAUGE, OIL TEMP
OIL AND FUEL PRESSURE, .
22. VOR/LOC NAVIGATION INDICATOR
23. VERTICAL SPEED INDICATOR
24. LIGHT CONTROL AND DIMMING
SWITCH, INST.PANEL,& RADIOS
25. OPTIONAL EGT (Exhaust Gas Temprature
Gauge) when Standard Instrument Package
installed.
26. MIC/PHONE JACKS
27. ELT CONTROL
28. INTERCOM CONTROL
29 CIGAR LIGHTER
Typical VFR Panel
