Pipishell PILTK4 - Supplied Hardware

Hardware for Attaching TV Bracket to TV
x4 x8 x8
Philips Screws
M4 x 12mm
M4 x 30mm
x4x4
M-A M-B
Philips Screws
M6 x 15mm
M6 x 30mm
x4x4
M-C M-D
x4
M-E
x4
M-F
Philips Screws
M8 x 15mm
M8 x 45mm
M8 x 65mm
x4
M-G
M-I
Spacers
L10mm
M-J
Spacers
L5mm
M-H
Washers
φ6mm
M4-5-6
Supplied Hardware
Hardware for Attaching Wall Plate to Wall
Lag Bolts
ST7X55
x4 x4
A
These anchors are for concrete
or brick walls ONLY. DO NOT use
them in drywall or wood studs.
CAUTION!
B
Wall Anchor
2
φ10MM
