Pit Boss 820FB - Parts Identification and Replacement

PARTS LIST
Page 29
REPLACEMENT ITEMS
Section Four: TROUBLE SHOOTING
Item Part # Description QTY
1. 76122 Upper Rack 1
2. 7403
5 Cooking Grids
2 or 3
3. 7451
6 Flame Broiler—main
5.
7
43
22
Handle—Chrom
e
1
6. 7422
8 Bezel,
(decorative washer) 2
7.
Barrel & Hopper Assembly
1
8.
74321 Leg w/ Wheel axle
(right hand side end)
2
9.
7434
7
74348
Bottom Shelf
820FB—Open Grid
820Deluxe—solid
1
10.
74086 Metal Wheel 2
11 a. 74322 Back Leg
(hopper end) 1
11 b. 74323 Front Leg w/bottle opener
(hopper end)
* Deluxe models only
12. 7440
0 Grease Bu
cket
1
13.
7422
2
Handle—Side (tray holde
r)
820
Deluxe
— Stainless
1
14. 7408
0 Smoke Stac
k
1
15. 7480
1 Smoke Stack—Ga
sket
1
16. 7440
2 Dome Thermo
meter
1
17. 7440
3 Lid Stoppe
r
1
18. 7432
8 Bottle Opene
r
(820Deluxe only)
1
19.
74223 Serving Tray (820DG only) 1
4.
Flame Broiler—slide
