Section One: ASSEMBLY INSTRUCTIONS
ASSEMBLING & MOUNTING THE LEGS & SHELF
Tools Required:
1– Phillips Screwdriver
Installation Steps
2 Legs w/ wheels
Step 1 Attach legs to barrel:
To ease installation, gently lay the barrel on its end,
not the hopper end.
A piece of cardboard or blanket should be placed under
the grill to prevent scratching the finish.
Usi
ng the proper tool, install the 2 legs WITHOUT the
wheel to the top of the barrel. (hopper end)
Part # 13 & 14
Fasten all four 1/4” - #20 x 1/2” screws (A) through the
four pre-drilled screw holes both on the leg and
on the bottom of the barrel. Hand start, then use tool.
FASTEN ONLY, DO NOT TIGHTEN AT THIS POINT.
THIS ALLOWS FOR EASIER INSTALLATION OF
BOTTOM SHELF.
Install the 2 legs WITH the
wheels to the bottom of the
barrel. Part # 10 & 11
Reminder: Leg with Bottle Opener faces out
toward the front of the grill. (model 440D only)
Fasten all four 1/4” - #20 x 1/2” screws (A) through the four
pre-drilled screw holes both on the leg and
on the bottom of the barrel. Hand start then use tool.
FASTEN ONLY, DO NOT TIGHTEN AT THIS POINT.
Page 7
Parts Needed:
Hardware Required:
2 Legs
1 Bottom Shelf
340—Open Grid
440D—Solid
Screw 1/4”- 20* 1/2” x 20 (A)
1 Barrel
#10, #11
#13, #14
# 6
#12
To Next Page
