ENGLISH
4
Part# Description
1 Main Cooking Grid
2 Upper Cooking Grid
3 Top Damper Vent
4 Ceramic Body
5 Lid Handle
6 Left Side Shelf Bracket (x2)
7 Right Side Shelf Bracket (x2)
8 Side Shelf (x2)
9 Charcoal Plate
10 Firebox
11 Long Support Bracket (x2)
12 Short Support Bracket (x2)
13 Support Bracket Crosspiece (x2)
14 Locking Caster Wheel (x2)
15 Caster Wheel (x2)
16 Ash Tool
Nut - Small (x16)
Nut - Large (x4)
Locking Washer (x16)
D Washer (x16)
E Screw (x16)
F Flat Wrench
G Wrench 9/11
H Wrench 17/19
I Screwdriver
NOTE: Due to ongoing product development, parts are subject to change
without notice. Contact Customer Service if parts are missing when
assembling the unit.
1
2
3
4
5
7
8
9
10
11
12
14
13
15
16
6
To Next Page
