Pitco SGH50 Full - Pump Assembly and Filter Pan

28
L22-235 Rev 1 (10/12)
Table 4
Pump Assembly and Filter Pan
Item# Part# Part Description
1 ..........................B4004501 ....................................... Full Return Handle
B4004601 ....................................... Left Split Return Handle
B4004701 ....................................... Right Split Return Handle
2 ..........................P0190200 ....................................... Cotter Pin 1/16”x3/4”
3 ..........................60131901........................................ Washer, Spring 5/8” with 5/16” Hole
4 ..........................P0080750 ....................................... Washer, Flat 5/16”
5 ..........................P0075400 ....................................... Screw, 10-24 X 1/2
6 ..........................A7020501 ....................................... Return Handle Bracket Cover
7 ..........................A7028001 ....................................... Return Handle Bracket
8 ..........................B5305001 ....................................... DVI Return Switch
9 ..........................PP10266 ......................................... 4-40 x 1/4” Screw
10 ........................ PP10266 ......................................... 4-40 x 1/4” Screw
11 ........................ PP10263 ......................................... DVI Return Actuator
12 ........................ P7037751 ....................................... 3/4” Street Elbow
13 ........................60136801........................................ 3/4” X 1/2” Street Elbow
14 ........................ 60130806........................................ 115/220VAC Pump & Motor Assembly
60130807 ....................................... 240VAC Pump & Motor Assembly
60130810 ....................................... 208VAC Pump & Motor Assembly
60130804 ....................................... 115/220V Motor Only
60130804 ....................................... 240VAC Motor Only
60130809 ....................................... 208VAC Motor Only
PP10417 ......................................... 5 GPM Pump Only
15 ........................ P6071516 ....................................... 3/4” x 4” NPT Nipple
16 ........................ A7027602 ....................................... Pickup Tube Receiving Block
17 ........................PP11104 ......................................... 1” x 1.18” viton O-ring (3 required)
18 ........................ A7008302 ....................................... Paper Support
19 ........................ B6671201 ....................................... Pickup Tube Strainer
20 ........................60131401........................................ Rigid Caster
21 ........................ B6673401 ....................................... Filter Pan Only (no casters)
22 ........................ B6673501 ....................................... Paper Hold Down
23 ........................ P7036603 ....................................... 3/4” NPT Coupling
24 ........................60131301........................................ 3/4” X 9” Nipple
25 ........................ PP10485 ......................................... 3/4” X 1/2” Elbow
26 ........................ P7037092 ....................................... 1/2” X 1-1/2” Nipple
27 ........................60132201........................................ Hose, fluropolymer swivel FxMPT
28 ........................ A8033801 ....................................... Flare Fitting Elbow
29 ........................60128008........................................ Tbg, Flex Return Line 0.5” x 15.5”
60128009 ....................................... Tbg, Flex Return Line 0.5” x 19”
60128010 ....................................... Tbg, Flex Return Line 0.5” x 22”
60128011 ....................................... Tbg, Flex Return Line 0.5” x 10”
30 ........................60131801........................................ Return Valve
31 ........................ 60130001........................................ End Cap
32 ........................60130101........................................ Tank Return Fitting
Additional Parts Not Shown
PP11323 ......................................................................................Filter Paper
60133503 ......................................................................... 120V Heat Tape (pump)
60133504 ...................................................................... 230/240V Heat Tape (pump)
60133501 ...................................................................... 120V Heat Tape (flush hose)
60133502 .................................................................. 230/240V Heat Tape (flush hose)
