5.4.1 digital lfo
The midi module includes a digital lfo with two identical [lfo output]s. The
frequency of the digital lfo is based on the active clock source. The active clock
source can be the internal clock, external midi clock, or external gate clock. The
digital lfo waveforms are positive voltage only and are centered around 5v."
Waveforms available include triangle, random, ramp, saw, digital noise, and
sine. Pressing the [lfo button] cycles through the available waveforms. "
5.4.2 selecting the digital lfo clock division
The digital lfo can run at a division or multiple of the active clock source. To
select a clock division, Press and hold the [lfo button] then tap the [clock
button] to cycle through the digital lfo frequency divisions. The selected
digital lfo clock division is saved in memory and recalled when the Lifeforms
SV-1 module is powered on."
1. Clock = - lfo frequency matches the active clock source."
2. Clock x2 - lfo frequency is double the frequency of the active clock source."
3. Clock x3 - lfo frequency is triple the frequency of the active clock source."
4. Clock /2 - lfo frequency is half the frequency of the active clock source."
5. Clock /4 - lfo frequency is a quarter the frequency of the active clock source.
