5.5.1 midi cc expression output
The [cc output jack] outputs a 0v to 5v voltage based on assigned midi cc
number. This jack can be assigned to a midi keyboard mod wheel or assignable
knob. The [cc output jack] can also be assigned to a midi cc channel used by a
daw.
5.6 midi velocity expression output
The [velocity output jack] outputs a 0v to 5v voltage based on the midi velocity
messages. This voltage can be patched into the [frequency cv input jack] to
modulate the frequency of the filter.
5.5.2 selecting the midi cc source
The midi cc source is selected in the edit mode. Enable edit mode by pressing
and holding the [edit button] down for 1 second. The [mono led], [arp led],
[gate led], and [clock led] will blink 3 times to indicate edit mode is enabled."
Once in edit mode, the midi module assigns the cc channel based the last
incoming cc message it receives. Simply move a mod wheel or turn a knob to
assign that midi cc number to the midi module. The cc source is saved in
memory and recalled when the Lifeforms SV-1 module is powered on."
Disable edit mode by pressing and holding the [edit button] down for 1
second. The [mono led], [arp led], [gate led], and [clock led] will blink 3 times to
indicate edit mode is disabled.
