Pivot 3 drive BLP User Manual

8
START
ENGINE
STOP
Press the
switch for
3 seconds
Release
Press
3 seconds
Features
Connecting
The Wires
Installing
The Product
How to
Operate
Speed Pulse
Settings
Before
Using
Trouble-
Shooting
Initial
Settings
Accelerator
Degree of acceleration
Time length of operation
Range of settings
Adjustment unit
[Value of settings]
Basic value of settingsInitial value
Engine Start.
Degree of acceleration
（30–50 %）
Time length of operation
（0.2–0.6 sec）
The speed at which
blipping starts
（30–60 km/h）
Press the SET switch to
select the desired setting
mode.
(Blinking)
Setting Completed
Press the UP / DOWN
switches to select the
desired setting.
Back to normal display
with no operation for 3
seconds or pressing
the BLP switch.
Adjust Please increase gradually from the minimum adjustment.
The minimum speed of
blipping start
If
nor
does not appear, press the
MODE switch until
nor
appears.
Press the DOWN switch
for 3 seconds.
2
Release the DOWN switch.
3
Press the UP / DOWN switches to select
the desired pulse setting.
4
Speed Pulse Settings
Operating the Auto-Blipping
Make sure to set the car’s speed pulse settings correctly. If the
pulse settings are incorrect, the Auto-Blipping will not work with
the setting speed.
Setting
Completed
ON
or
(Engine not running)
(NORMAL Mode)
1
65
(Factory Setting)
procedure 4
For details about Pulse settings, see the “Wiring
Char t” .
•
nor
will
appear.
•
PLS
will
appear.
Without press
the clutch, press
down twice
• The pulse number
will appear.
If no operation is
carried out for 3 sec-
onds, the display will
begin blinking.
If no operation is carried out
for 5 seconds, the display
will change from blinking to
NORMAL Mode.
Values
Up
Values
Down
3
4
BLIPPING is the action to increase Engine Rotation which decreased by braking. When using blipping to
raise the Engine Rotation, it is possible to fine tune the settings for degree of acceleration, time length
of operation and the speed at which blipping starts.
In operation of Auto-Blipping with 3rd gear and about 3000rpm, basically Engine Rotation will increase about 1000rpm.
Adjusting Auto-Blipping
2
1
START
40–50 %
0.3–0.5 sec
50 km/h
30–50 %
0.2–0.6 sec
30–60 km/h
30 %
0.2 sec
30 km/h
10 %
0.1
sec
10 km/h
• Since Auto-Blipping is a useful function for sports driving, please set to OFF in the city.
• If it is slightly accelerated when releasing the clutch pedal, please adjust Auto-Blipping setting values lower
because the values might be too high.
Although amount of increase in engine rotation on Auto-Blipping is different by car performance and driving conditions, basically it could
be the most suitable settings that cause less acceleration and deceleration when releasing the clutch pedal in addition to downshift
smoothly.
or
Press
Turn the ignition to
the ON position.
