Start the Test Run.
(40 km/h, not lower
than 3rd gear)
Engine
Start.
Please carry out the test drive in a safe spacious area away from pedestrians and traffic.
Please make sure to carefully read this manual and understand how to operate the unit before taking a test run.
After having carried out all of the necessary wiring and making settings in “Initial Settings” and
“Speed Pulse Settings” please carry out a Auto-Blipping test.
Press the SET switch to make each setting.
Press the BLP switch.
341
1
Start Running.
(Setting speed or above.)
234
Release the clutch.
(Downshift completed.)
Auto-Blipping
ON
Auto-Blipping
OFF
Dot light on
ON
Dot light off
OFF
Set When the engine starts, Auto-Blipping is OFF. Need to turn ON when it used.
Activate Depress the Clutch while stepping on the brake, blipping works automatically.
Engine Start.
START
2
Mode Display
2
(Test setting values: A30, t 0.2, S30)
See page 8 to 9 for details.
3
4
(Make sure the dot blinks.)
1
Depress the clutch pedal
while stepping on the brake.
(When pressing the clutch, the speed
must be not lower than 30 km/h.)
56
Auto-Blipping Test
[Reference 2] Example of settings
Car model
Degree of
acceleration
40%
30%
Vitz
Time
0.3 sec
0.3 sec
40%
CR-Z
86/BRZ
0.3 sec
40%
Civic(FD2) 0.4 sec
Car model
Degree of
acceleration
SWIFT(ZC31S) 30%
Time
0.4 sec
COLT
30%
0.4 sec
IMPREZA(GRB)
40%
30%ROADSTER(NCEC)
0.3 sec
0.3 sec
• Poor settings of “Initial Settings” and “Speed Pulse Settings” . (See page 7 to 8)
• Poor connection of and . (See page 4 to 5)
• Poor connection of Clutch adapter. (See page 4)
• Not reached at the set speed. (See page 8)
• Auto-Blipping setting value is too low. (See page 8 to 9)
• Not enough to press the Clutch pedal.
6
Gray Or
ange
[Reference 1] Speed and rpm of each gear (SUZUKI SWIFT ZC31S）
1st
1st
1st 2nd
2nd
2nd 3rd
3rd
3rd 4th
4th
4th
5th
5th
5th
0
1000
2000
3000
4000
5000
6000
7000
8000
20 40 60 80 100 120 140 160 180 200
Speed (km/h)
Engine Rotation (rpm)
Since the amount of increase in engine rotation changes
depending on the car setting mode, please adjust blipping
settings according to the setting mode.
e.g. HONDA CR-Z 3-mode drive system
NORMAL 1000rpm
SPORT
ECON
1800rpm
400rpm
Auto -Blipping
function operate.
(The rpms increase.)
Depress the clutch
while stepping on
the brake.
Setting mode of
car side
Press
Back to normal display with no
operation for 3 seconds.
Auto-Blipping
function operate.
(The rpms increase.)
If Auto-Blipping will
not operate
Check the right if Auto-Blipping will not
work at .
Settings of the car with standard “Acceleration
switching function” .
Note: “Acceleration switching function” is about a standard
function which switches acceleration like SUBARU SI drive and
HONDA 3-mode drive system.
Amount of increase
in engine rotation
Note: You can check the ON / OFF, by checking
the dot lighting or not on normal display.
Change with each
pressing of the
BLP switch.
