10 - ATR121 - User manual
1.4
Environmental policy / WEEE
Do not dispose electric tools together with household waste
material.
According to European Directive 2012/19/EU on waste
electrical and electronic equipment and its implementation
in accordance with national law, electric tools that have
reached the end of their life must be collected separately and
returned to an environmentally compatible recycling facility.
2
Model identification
ATR121-AD
12..24Vac ±10% 50/60Hz
12..35Vdc
ATR121-B
230 Vac ±10% 50/60 Hz (galvanical isolation
2500V)
3
Technical features
3.1
General features
Display
3 displays (0,56 inch) on ATR121
+ 3 leds (OUT1, OUT2 , L1)
Environmental
conditions
Temperature 0-45 °C, Humidity 35..95
uR% (without condense)
Max. altitude: 2000m
Sealing
Front panel: IP54 (IP65 with gasket) - Box:
IP30 - Terminals: IP20
Material Polycarbonate UL94V2 self-extinguishing
Weight Approx. 100 gr.
Power
consumption
ATR121-B: 3 VA max
ATR121-AD: 2,4 VA max
