Page #28 background image
28 - ATR121 - User manual
02
sen
Sensor
Analogue input configuration.
For a correct functioning of the device, use sensors
insulated from the ground. Otherwise, use a single
transformer isolated for each instrument.
tck
Tc-K -260 °C..1360 °C (default)
1 p. 40
tc.s
Tc-S -40 °C..1760 °C
1 p. 40
tc. r
Tc-R -40 °C..1760 °C
1 p. 40
tc. j
Tc-J -200 °C..1760 °C
1 p. 40
pt
PT100 -200 °C..600 °C
p t1
PT100 -200 °C..140 °C (restricted range)
ni
Ni100 -60 °C..180 °C
ntc
Ntc 10KΩ -40 °C..125 °C
ptc
Ptc 1KΩ -50 °C..150 °C
pts
Pt500 -100 °C..600 °C
p1 k
Pt1000 -100 °C..600 °C
0 .1 0
0..10V
0.20
0..20mA
4.20
4..20mA
p o1
Potent. ≤ 6KΩ F.S.
po2
Potent. ≤ 150KΩ F.S.
03
d . p.
Decimal point
Selects number of displayed decimal points.
0
No decimal (default)
0.0
1 decimal
0.00
2 decimals
04
Lo . s
Lower Limit Setpoint
-199..999
Value expressed in degrees.tenths for temperature sensors
or in digits
2 p. 40
for linear sensors and potentiometers
(default 0.0).
