30 - ATR121 - User manual
10
cA.G
Gain calibration
Percentage value that is multiplied for the process value
(allows to calibrated the working point)
-19.9%..99.9%. Percentage (default 0.0)
11
ReG.
Regulation type
HEA
Heating (N.A.) (Default)
coo
Cooling (N.C.)
m . r.
Absolute alarm with manual reset
m.r.m
Absolute alarm with manual reset and relay
status stored in case of power failure.
H.o.o
Heating with PID always to 0 if the
process is over the setpoint.
12
S. c. c.
Command state error
State of contact for command output in case of error
c. o.
Open contact (default)
c. c.
Closed contact
13
Ld1
Command led
State of the OUT1 led corresponding to the relevant
contact
c. o.
ON with open contact
c. c.
ON with closed contact (default)
14
HY. c
Command hysteresis
Hysteresis in ON/OFF or dead band in PID
-199..999
Value expressed as degrees.tenths for temperature
sensors and digits
2 p. 40
for linear sensors and potentio-
meters (default 0.0)
