29 EN
12 Confi guration EASY-UP
To Simplify the setting of parameters and the integration of the different
components involved in the control system, Pixsys introduces the EASY-
UP coding which allows to set sensors and/or command outputs in one
single step.
By means of the code listed in the data sheet enclosed to the sensor or
actuator (SSR, motorized valve, etc.) the EASY-UP coding will set the
relevant main parameters on the controllers (ex. selection of PT100
on parameter “Sensor” and the corresponding measuring range on
parameters “Lower and Upper limits of the setpoint”).
Different codes may be entered on the controllers in sequence to
confi gure inputs, control output or retransmission of signal.
