27
Configuration plan
Date: Model ATR241-
Installer: Plant:
Notes:
Select type of command output
Configuration of analog input
Visualization of decimal point
Lower limit of setpoint
Upper limit of setpoint
Lower limit An1 only for V/I
Upper limit An1 only for V/I
Offset calibration of sensor input
Gain calibration of sensor input
Type of action (Hot, Cool)
Select state of led 1
ON/OFF hysteresis or P.I.D. dead band
Proportional band
Integral time (0 excludes integral)
Derivative time (0 excludes derivative)
Cycle time for time-proportioning output
Limit of control signal
Type of alarm
State of contact for alarm output
Select state of led 2
Alarm hysteresis
Protection of set 2
Software filter on analog input
Type of autotuning
Soft start
Hold time for programmed cycle
Type of operating
