4
3. Electrical wirings
Altough this controller has been conceived to resist
the worst noises in an industrial environment, please
notice the following safety guidelines:
• Separate control wires from power wires
• Avoid mounting close to remote control switching
systems, electromagnetic relays, powerful engines
• Avoid proximity of power systems, especially those
with phase control
3.1 Wiring plan
10
9
8
7
6
5
4
3
2
1
SUPPLY
OUT
OUT2 SSR/mA
+
-
TC
+12
V/A
12/24V AC/DC
115V AC
230V AC
24V AC
