7
Power supply
24…12V AC/DC ±15%
230/115V AC ±15% 50/60Hz (selection
by internal jumper C01)
24V AC ±15% 50/60Hz
Code ATR241-BC
Select CO1 as in the picture for
115Vac supply
Code ATR241-BC
Select CO1 as in the picture for
230Vac supply
Relay output Out1
Contacts capacity 8A/250V~ resistive
Operating with available configurations:
Command relay : select parameter 1
as
Valve-opening relay with
configuration Open/Close
Alarm relay 1 with SSR output or
output 0/ 4..20mA
