Finalize Installation
42. Fit the Top Side panels 43. Make sure to put the screw between
the Top Side panels and the Eyebrow
hood
41. Bend oven metal tabs to secure flue
connection
44. Remove the wooden stone supports 45. For ventilation reasons, position the
oven leaving 50 mm (2”) between the
oven and any adjacent wall
46. Position the oven over a flat floor,
so the oven is horizontal and stable
47. If possible, position the oven with
easy access to the right hand panel to
facilitate the electrical installation and
future services
48. Read the Owner´s manual to install
other accesories
CONGRATULATIONS!
Your PizzaMaster oven is now installed.
DO NOT remove the ”Quick Start Guide”
from the handle before the first use
Installation – Assembly oven
