Accesories Assembling
32. Secure the slide rails with the 4
hexagonal screws (provided)
37. Attach the back flue diverter, using
3 self-tapping screws (wafer head,
provided)
33. Insert the sliding shelf into either the
upper or the lower pair of rails (1 shelf
provided as standard). Order a second
shelf separately as an accesory
38. Place the Eyebrow hood piece 39. Attach front Eyebrow piece with
self-tapping screws (wafer head)
40. Place the front flue diverter
35. Use 2 self-tapping screws per
blocker
34. To place the shelf blockers, pull out
the shelf and place them behind both
front legs. With two shelfs, place two on
the top and two on the bottom
36. Fit the shelf blocker and repeat in the
other front leg
Installation – Assembly oven
