28. Tighten the bolts alternately for better
fit. Hand tight all first
29. Make sure that all the legs are firmly
and well adjusted
27. Let the bolt loose and rotate the leg
180°
25. Use these hex bolts to place the legs,
follow the next steps. (Continue at step
26)
Continue here for all models
26. Use 3 bolts M10x30 and 1 washer per
bolt 20x10.5 (provided). Rotate the leg
180° out to place the inside bolt first,
30. DO NOT remove the pallet truck/
genie lift before placing the leg cut-
outs
31. Fit all four shelf slide rails in place
in the leg cut-outs
Support Assembling
Installation – Assembly oven
1
2
3
2
3
1
1
