Planet Audio P9759B User Manual

. Radio Operation
Touch this button to adjust the brightness of TFT panel
.
Touch this button to return to main menu
Touch button go to EQ setting
DVD Operation
DVD Player
To start DVD player, tap on DVD button from main menu screen.
Touch Screen Menu
You will not see any buttons while DVD is played, buttons will appear when you tap on TFT screen. Tap
the screen again to hide the buttons, slide the subtitle part of bottom screen to switch the following 2
pages.
Note:
1. DVD player will automatically start playing when you insert the DVD disc.
2. Suggest that don’t watch video if the vehicle is moving for driver's safety.
3. DVD Player will not only play video, but picture and music files as well.
Touch it to enter to previous/next page menu.
Touch it skip to the previous track
Touch it skip to the next track
Touch it to pause/play
Touch it to select the sound track in the sequence of mono L => mono R =>auto L => auto R
=>stereo
Touch it choose brightness
Zoom the image in or out in the sequence of ×2×3×4×5×1/2× 1/3 ×1/4
In DVD mode, touches it chooses Repeat 1=>repeat title =>repeat all. In VCD mode, touch it
can choose REP 1 => REP DIR => REP ALL
13

Planet Audio P9759B Specifications

General

MP3 playback	Yes
Playback disc formats	CD audio, DVD-Audio, DVD-Video
Audio formats supported	MP3, MP4, WMA
Image formats supported	JPG
Video formats supported	AVI
Supported radio bands	AM, FM
Preset stations quantity	30
DIN size	1 DIN
Output power	340 W
Product color	Black
Ready for iPod	No
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Maximum power per channel	85 W
Display diagonal	7 \
USB version	2.0
USB ports quantity	2
Bluetooth functions	Audiostreaming, Handsfree calling
Compatible memory cards	SD

Weight and Dimensions

Dimensions (WxDxH)	181 x 54 x 190 mm
