Planet Audio P9759B User Manual

General Specification
General
Power supply 11~16V DC
Current consumption Max. 10 A
Maximum power output 80W x 4 channels (max)
Compatible formats DVD ±R/RW Video, CD ±R/RW Audio & Video
Dimensions (W x D x H) / weight 7.0” x 6.4” x 2.0” /3.9 lbs
Working temperature range
-4°F -- +140°F
ESP function 10 sec. for Audio CD, 120 sec. for MP3
TFT display
Screen size 7.0 inch
Resolution 800*480 pixel
Aspect ration 4:3/16:9
Brightness
460 cd/㎡
Contrast ratio 500:1
FM radio
Frequency range(Europe area) FM:87.5 –108MHz(Step 50KHz)
Frequency range(America area) FM:87.5 –107.9MHz(Step 200KHz)
Frequency range(Asia area) FM:87.5 –108MHz(Step 100KHz)
Frequency range(South America area) FM:87.5 –108MHz(Step 100KHz)
Frequency range(Russia area) FM:87.5 –108MHz(Step 50KHz) 65-74MHz(Step
30KHz)
Preset memory stations 18
AM(MW)radio
Frequency range(Europe area) AM:522-1620(Step 9KHz)
Frequency range(America area) AM:530-1710(Step 10KHz)
Frequency range(Asia area) AM:531-1602(Step 9KHz)
Frequency range(South America area) AM:520-1710(Step 10KHz)
Frequency range(Russia area) AM:522-1620(Step 9KHz)
Preset memory stations 12
Audio specification
Frequency response 20 Hz-20 KHz
TV Color System Color system NTSC/PAL
USB interface
USB type USB 2.0 full speed
Support format MP3 , WMA, MPEG1, MPEG2, AVI
Specifications are subject to change without notice, mass and dimension are approximate.
23

Planet Audio P9759B Specifications

General

MP3 playback	Yes
Playback disc formats	CD audio, DVD-Audio, DVD-Video
Audio formats supported	MP3, MP4, WMA
Image formats supported	JPG
Video formats supported	AVI
Supported radio bands	AM, FM
Preset stations quantity	30
DIN size	1 DIN
Output power	340 W
Product color	Black
Ready for iPod	No
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Maximum power per channel	85 W
Display diagonal	7 \
USB version	2.0
USB ports quantity	2
Bluetooth functions	Audiostreaming, Handsfree calling
Compatible memory cards	SD

Weight and Dimensions

Dimensions (WxDxH)	181 x 54 x 190 mm
