PLANET ECLIPSE ETHA2 - Solenoid Assembly

FIG-1
28
ETHA2 PAL
TECHNICAL
SOLENOID ASSEMBLY
Solenoid spool
Solenoid plug
Solenoid pilot
Solenoid body
Solenoid gasket
M2 x 16
cross pan-head screw
Solenoid
plate
Solenoid gasket
#6 seal (custom)
M1.6 x 5
machine screws
#6 seal (custom)
6 x 1 NBR70
