PLANET ECLIPSE ETHA3 - Quick Start: Setting Up

Etha3 etha3
06 07
SUB TITLE SETTING UP
Etha3 etha3
06 07
SETTING UP
Warning !
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or used
incorrectly.
Only attach an air system certied for use within the country of use.
Never add lubricants or grease into the ll adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you feel
condent with your ability to handle the marker safely and responsibly.
A
I
H
G
F
E
B B C
D
Fig.1
FIG.1
A Switch the marker OFF before you begin.
This ensures the marker will not re when the trigger is pulled.
B Attach the barrel.
Rotate the barrel tip counter-clockwise into the back section.
Rotate the barrel back clockwise into the marker body.
C Attach a barrel blocking device for safety.
D Attach the preset air system.
Rotate the air system clockwise into the ASA body.
E Loosen the clamping feed neck.
Open the feed neck lever away from the feed neck.
Rotate the feed neck lever screw counter-clockwise.
F Attach the loader.
Loosen the clamping feed neck if it’s too tight.
G Secure the loader.
Close the feed neck lever to secure.
Rotate the feed neck lever screw clockwise to tighten.
H Gas the marker.
Push the POPS switch towards the POPS body until it engages.
I Switch the marker ON when you are ready to play.
The marker will now re when the trigger is pulled.
! IMPORTANT! To switch the marker ON/OFF see page 8.
! DO NOT over-tighten the barrel.
! ALWAYS ensure marker is de-gassed when setting up.
! NEVER use CO2. Only use compressed air or Nitrogen.
