PLANET ECLIPSE ETHA3 - Electronics: The Set-Up Mode; Modifying a Parameter; Electronics: Presets

Etha3 etha3
16 17
SUB TITLE PRESETS
To modify the control parameters you must access the set-up mode:
1 Fully depress and hold the trigger.
2 Switch on the marker.
3 The status indicator should ash WHITE.
4 Release the trigger.
If the status indicator ashes RED then access to set-up is denied
because the tournament lock is still on. Turn off the tournament lock
(page 33) and try again.
Once in set-up mode, use the trigger to cycle through the parameters,
indicated by the colour of the status indicator (see table below).
Quickly press the On/Off button to display the current parameter value.
A long LED ash indicates the unit, whilst a short LED ash indicates the
tenth. E.g. 5 long ashes and 3 short ashes would indicate 5.3.
MODIFYING A PARAMETER
1 Enter the set-up mode.
2 Select a parameter using the trigger.
3 Push and hold On/Off button for 1 second to select.
4 The LED will go off.
5 Increase the unit value using the trigger, one pull per unit.
6 Push the On/Off button to switch to tenths values.
7 Increase the tenths value using the trigger, one pull per tenth.
Do not pull the trigger if the value should be 0.
8 Push the On/Off button to conrm. The status indicator will
ash 3 times: GREEN if the value is accepted, RED if the value
is invalid. If the status indicator was red then try again.
9 Push and hold the On/Off button until the status indicator turns
BLUE to exit set-up mode.
To reset all of the parameters to their factory-set default values press
and hold the tournament lock button for 2 seconds while in set-up
mode. The status indicator will ash BLUE when the parameters have
been reset.
1 The settings will return to their previous saved values if you do
not pull the trigger for 5 seconds.
2 If a parameter does not support tenths, this will be skipped.
Etha3 etha3
16 17
THE SET-UP MODE FAULT FINDING TABLES
Led colour parameter range
Red Preset 1 to 4
Green
Maximum ROF with BS on
(capped modes only)
4.0 to 15.0 bps
Blue Maximum ROF with BS off 4.0 to 15.0 bps
Purple Dwell 18 to 28
Light Blue Debounce 1 to 10
The Preset parameter is used to quickly set up the marker to operate
within the rules of the most common paintball leagues. Simply set the
Preset parameter to the required value as shown in the table below.
The rate of re caps used by the presets are safe values to allow for
variations in rate of re measuring equipment.
To change the rate of re, rst set the preset parameter and then set
the two maximum ROF parameters (GREEN and BLUE).
value mode description
1 SEMI ∞ Uncapped Semi-Automatic: one shot per trigger pull with no rate of re cap.
2 SEMI 15.0 Capped Semi-Automatic: one shot per trigger pull with 15.0 bps rate of re cap.
3 NXL NXL compliant ramping with a 10.2 bps rate of re cap.
4 PSP PSP compliant ramping with a 10.2 bps cap and 1.0 ms restart.
