SUB TITLE UNLOADING THE MARKER
Etha3 etha3
12 13
UNLOADING THE MARKER UNLOADING THE MARKER
Warning !
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or used
incorrectly.
Only attach an air system certied for use within the country of use.
Never add lubricants or grease into the ll adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you feel
condent with your ability to handle the marker safely and responsibly.
FIG.1
A Switch the marker OFF before you begin.
This ensures the marker will not re when the trigger is pulled.
B Attach a barrel blocking device for safety.
C De-gas the marker.
Push and hold the POPS button then pull the POPS switch
away from the POPS body.
D Remove the preset air system.
Rotate the air system counter-clockwise from the ASA body.
E Loosen the clamping feed neck.
Open the feed neck lever away from the feed neck.
Rotate the feed neck lever screw counter-clockwise.
F Remove the loader.
If the feed neck is too tight, loosen the clamping feed neck
more.
G Remove the barrel.
Rotate the barrel counter-clockwise from the marker body.
H Separate the barrel sections.
Rotate the barrel tip clockwise from the barrel back.
! IMPORTANT! To switch the marker ON/OFF see page 8.
! ALWAYS attach a barrel blocking device to avoid injury.
! ALWAYS remove air system before unloading.
! ALWAYS remove any paintballs from the breech of the marker
once the loader has been removed.
Fig.1
A
C
F
E
G H B
D
