FNSW-16/24 User's Manual
9
2.2.3 Status LEDs
One green LED to show power On/Off is on the front panel. Also,
each port has three status LED indicators, as shown below.
Label Status /
Color
Meaning Description
Steady
Green
Link Lit to indicate a valid physical
UTP/STP connection exists
L
OWER
R
OW
Blink
Green
Active Blink to indicate the port is
receiving data packets
M
IDDLE
R
OW
Steady
Green
100M Lit to indicate that a valid
physical UTP/STP connection
exists on that port runs in
100Mbps
Steady
Orange
Full-Duplex
Lit to indicate Full-Duplex
mode detected on that port
U
PPER
R
OW
Blink
Orange
Collision
Blinks if a collision is detected
when the port is in Half-Duplex
mode.
Table B: The Switch's Port-LED Functions
