User’s Manual of IGS-4215-16T2S
175
-Replace - The new multicast group replaces an existing group.
Buttons
: Click to apply changes.
Figure 4-7-4: IGMP Port Max Groups Information Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Max Groups
Displays the current Max groups.
• Action
Displays the current action.
4.7.3 Multicast Profile Setting
The Add Profile and Profile Status screens in Figure 4-7-5 and Figure 4-7-6 appear.
Figure 4-7-5: Add Profile Setting Page Screenshot
