User’s Manual of IGS-4215-16T2S
222
Buttons
: Click to apply changes.
Figure 4-11-4: Dynamic Addresses Status Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
Displays the current aging time.
4.11.3 Static MAC Setting
The static entries in the MAC table are shown in this table. The MAC table is sorted first by VLAN ID and then by MAC address.
The Static MAC Setting screens in Figure 4-11-5 and Figure 4-11-6 appear.
Figure 4-11-5: Statics MAC Setting Page Screenshot
The page includes the following fields:
Object Description
• MAC Address
Physical address associated with this interface.
• VLAN
Select VLAN from this drop-down list.
• Port
Select port from this drop-down list.
Buttons
: Click to add new static MAC address.
