User’s Manual of IGS-4215-16T2S
229
Figure 4-12-6: Queue Information Page Screenshot
The page includes the following fields:
Object Description
• Information Name
Displays the current queue method information.
• Information Value
Displays the current queue value information.
4.12.2.4 CoS Mapping
The CoS to Queue and Queue to CoS Mapping screens in Figure 4-12-7 and Figure 4-12-8 appear.
Figure 4-12-7: CoS to Queue and Queue to CoS Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list.
• Class of Service
Select CoS value from this drop-down list.
