Users Manual of IGS-4215-16T2S
73
V3: Reserved for SNMPv3 or User-based Security Model (USM)
Security Level
Indicates the security model that this entry should belong to.
Possible security models are:
Noauth: None authentication and none privacy security levels are
assigned to the group.
auth: Authentication and none privacy.
priv: Authentication and privacy.
Note: The Security Level applies to SNNPv3 only.
Read View Name
Read view name is the name of the view in which you can only view the contents of
the agent.
The allowed string length is 1 to 16.
Write View Name
Write view name is the name of the view in which you enter data and configure the
contents of the agent.
The allowed string length is 1 to 16.
Notify View Name
Notify view name is the name of the view in which you specify a notify, inform, or trap.
Buttons
: Click to add a new access entry.
: Check to delete the entry.
Figure 4-2-26: SNMP View Table Status Page Screenshot
The page includes the following fields:
Object Description
Group Name
Displays the current SNMP access group name.
Security Model
Displays the current security model.
Security Level
Displays the current security level.
Read View Name
Displays the current read view name.
Write View Name
Displays the current write view name.
Notify View Name
Displays the current notify view name.
Action
: Delete the access group entry.
