5. Three-View Diagram
IPOE-270
115.00
41.00
70.00
18.00
3.50
103.00
5.50
30.00
50.00
28.65
27.19
159.00
Top View
Side View Front View
Mounting Kit
Mounting Kit
DIN-Rail Kit
Side View
Rear View
Unit: mm
Bottom View
P1 P2
60W 120W 180W
PoE
Usage
Ethernet
Ethernet
IPOE-270
PoE++
PoE++
BT Legacy
V1+
V2+
PWR1
PWR2
DC Input:
48-54V
, 4A max.
Figure 5: IPOE-270 Three-View Diagram
