2.ProductSpecications
Model IPOE-270 IPOE-270-12V
HardwareSpecications
Copper Ports
2-pair 10/100/1G/2.5G/5GBASE-T RJ45:
 Data input port 1 and PoE output port 1
 Data input port 2 and PoE output port 2
Connector
Removable 4-pin terminal block
Pins 1 and 2 for Power 1; Pins 3 and 4 for Power 2
LED Indicator
System:
Power 1 (Green)
Power 2 (Green)
PoE Usage:
60W/120W/180W (Amber)
802.3bt PoE++ Port:
PoE-in-use x 1 (Green: bt, Amber: at)
Network Cable
Twisted-pair cable up to 100 meters (328ft)
10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6
100BASE-TX: 4-pair UTP Cat. 5, 5e, 6
1000BASE-T: 4-pair UTP Cat. 5e, 6
2.5G/5GBASE-T: 4-pair UTP Cat. 6, 6A, 7
Data Rate 10/100/1000/2500/5000Mbps
Power
Requirements
48~54V DC, redundant power
with reverse polarity protection
12~54V DC, redundant power
with reverse polarity protection
Power
Consumption
(Ethernet Full
Loading)
System ON without loading
48V DC: 1.4 watts/4.7BTU
52V DC: 1.5 watts/5.1BTU
54V DC: 1.6 watts/5.4BTU
Full loading with PoE
48V DC (120W PoE budget):
128 watts/436BTU
52V DC (180W PoE budget):
177 watts/603BTU
54V DC (180W PoE budget):
187 watts/638BTU
System ON without loading
12V DC: 1.8 watts/6.1BTU
24V DC: 2.4 watts/8.1BTU
48V DC: 2.4 watts/8.1BTU
52V DC: 2.6 watts/8.8BTU
54V DC: 2.1 watts/7.1BTU
Full loading with PoE
12V DC (60W PoE budget):
60 watts/204BTU
24V DC (120W PoE budget):
124 watts/423BTU
48V DC (120W PoE budget):
120 watts/409BTU
