Planet IPOE-E202 User Manual

9
Dimensions (W x D x H) 199.6 x 81 x 40 mm
Weight 373g
Power Consumption
30 watts/102.3BTU (Full loading with PoE
function)
Power over Ethernet
PoE Standard
PoE In Port
IEEE 802.3at Power over Ethernet Plus
end-span/mid-span PD class 4 PD
Per PoE Out Port
IEEE 802.3at Power over Ethernet Plus
end-span PSE
IEEE 802.3af Power over Ethernet end-span
PSE
PoE Power
PoE In Port
50~57V DC, max. 30.8 watts
Per PoE Out Port
44~55V DC, max. 25 watts
Power Pin Assignment
PoE In Port
1/2(+), 3/6(-); 4/5(+), 7/8(-)
Per PoE Out Port
1/2(-), 3/6(+)
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC 60068-2-32 (Free fall)
IEC 60068-2-27 (Shock)
IEC 60068-2-6 (Vibration)
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
Environment
Operating
Temperature: -40 ~ 75 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage
Temperature: -40 ~ 85 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
