Planet ISW-504PT User Manual

12
The Flow Control function allows Industrial Fast Ethernet Switch
supported routers and servers to directly connect to this device for fast,
reliable data transfer.
2.1.1 Switch Front Panel
Figure 2-1 & 2-2 & 2-3 show a front panel of Industrial Fast Ethernet
Switch.
Figure 2-1 ISW-504PT
front panel
Figure 2-2 ISW-514PT /
514PT15 front panel
Figure 2-3 ISW-514PTF
front panel
2.1.2 LED Indicators
¢ System
LED Color Function
P1 Green Indicate the power 1 has power.
P2 Green Indicate the power 2 has power.
Fault Green Indicate the either power 1 or power 2 has no power.
