7
® Integrated address look-up engine, support 2K absolute MAC
addresses
® CSMA/CD Protocol
Industrial Case / Installation
® IP-30 Aluminum Metal case / Protection
® DIN Rail and Wall Mount Design
® Redundant Power Design: 24 or 48V DC, redundant power with
polarity reverse protect function
® Supports EFT protection 6000V DC for power line
® Supports 6000V DC Ethernet ESD protection
® -40 to 75°C operating temperature
1.4 Product Specications
Model ISW-504PT ISW-514PT
Hardware Specication
10/100Base-TX Ports 5 4
100Base-FX interface N/A 1
IEEE 802.3af PoE ports 4 4
Dimensions (W x D x H) 135mm x 87.8mm x 56mm
Weight 842g
Power Requirement 24 or 48V DC
Installation DIN Rail Kit and Wall Mount Ear
Power over Ethernet
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Power Supply Type End-Span
PoE Power Output 48V DC Per Port, 350mA. Max. 15.4 Watts
Power Pin Assignment 1/2(+), 3/6(-)
