Installation Steps
Step 1: Unpack the Industrial M12 Ethernet Switch.
Step 2: Check the DIN-Rail is screwed on the Industrial M12 Ethernet Switch.
(Please refer to DIN-Rail Mounting section for DIN-Rail installation If the
DIN-Rail is not screwed on the Industrial switch). If you want to wall
mount the Industrial M12 Ethernet Switch, then please refer to Wall
Mount Plate Mounting section for wall mount plate installation.
Step 3: To hang the Industrial M12 Ethernet Switch on the DIN-Rail track or wall,
please refer to the Mounting Installation section.
Step 4: Power on the Industrial M12 Ethernet Switch. (Please refer to the M12
DC Power Cable Inputs) The power LED on the Industrial M12 Ethernet
Switch will light up. Please refer to the LED Indicators section for meaning
of LED lights.
