MB502 6” Deluxe Jointer
７
Loose Parts List
1 Fence
2 Jointer
3 Dust chute
4 Dust cover w/ dust collector adapter
5 Cutterhead guard
6 Hardware package (refer to following list for details)
7 For legs for stand
8 Two lower end braces for stand
9 Two lower side braces for stand
10 Two top side braces for stand
11 Two top end braces for stand
12 V-belt
13 Motor pulley
14 Motor with switch
15 Motor pulley and belt guard
29 Two push blocks
Parts List for Hardward Package
Carriage bolts M8x12 for assembling stand and dust chute to stand 36
Hex nuts M8 for assembling stand and dust chute to stand 36
Flat washers 8 for assembling stand and dust chute to stand 36
Carriage bolt M8x30 for assembling motor to dust chute 4
Hex nuts M8 for assembling motor to dust chute 4
Flat washers 8 for assembling motor to dust chute 4
Flat washers 10 for assembling motor to dust chute 4
Lock washers 8 for assembling motor to dust chute 4
Screws M5x16 for assembling switch box to stand 2
Hex nuts M5 for assembling switch to stand 2
Lock washer 5 for assembling switch to stand 2
Feet for stand legs 4
Special studs for assembling jointer to stand 3
Round handle for infeed and outfeed table adjustment 2
ASSEMBLY INSTRUCTIONS
WARNING: FOR YOUR OWN SAFETY, DO NOT CONNECT THE JOINTER TO THE
POWER SOURCE UNTIL THE JOINTER IS COMPLETELY ASSEMBLED AND YOU
HAVE READ AND UNDERSTOOD THE ENTIRE OWNERS MANUAL.
