User Manual of WNAP-6315
-8-
Chapter 2.
Hardware Installation
Please follow the instructions
below to connect WNAP-6315
to the existi
ng network devices and your computers.
2.1
Hardware Description
Dimensions
: 127 x 63 x 254 mm (W x D x H)
Figure 2-1
Three-way V
iew
Rear Panel – LED
Figure 2-2
LED
16
18
