User Manual of WNAP-6315
-77-
5.5.6 DMZ
This page allows you to set a De-militarized Zone (DMZ) to separate internal network and Internet.
Choose menu “Firewall DMZ”, and you can configure the private IP address of DMZ. The DMZ feature allows
one local host to be exposed to the Internet for a special-purpose service such as Internet gaming or video
conferencing. After the configuration, please click the “Apply Changes” button to save the settings.
Figure 5-6-2 DMZ
The page includes the following fields:
Object Description
Enable DMZ
Check the box to enable DMZ function. If the DMZ Host Function is
enabled, it means that you set up DMZ host at a particular computer to
be exposed to the Internet so that some applications/software,
especially Internet / online game can have two way connections.
DMZ Host IP Address
Enter the IP address of a particular host in your LAN which will receive
all the packets originally going to the WAN port / Public IP address
above.
5.6 QoS
The QoS (Quality of Service) helps improve your network gaming performance by prioritizing applications. By
default the bandwidth control are disabled and application priority is not classified automatically. In order to
complete this settings, please follow the steps below.
1. Enable this function.
2. Enter the total speed or choose automatic mode.
3. Enter the IP address or MAC address user want to control.
4. Specify how to control this PC with this IP address or MAC address, including maximum or minimum
bandwidth, priority and its up/down speed.
