Planet XGS-6311 Series - Setting 1000 Base-X For 10 G Sfp+ Port; Saving The Configuration

10
If the IP is successfully congured, the Managed Switch will apply the new
IP address setting immediately. You can access the Web interface of Managed
SwitchthroughthenewIPaddress.
If you are not familiar with console command or the related
parameter, enter “help” anytime in console to get the help
description.
4.3 Setting1000BASE-Xfor10GSFP+Port
The Managed Switch supports both 1000BASE-X and 10GBASE-X SFP
transceivers by manual setting and the default SFP+ port speed is set in the
ber auto mode,sotheend-usercanplugthetransceiverdirectly.
In another example, the end-user has to force the ber connection with
1000BASE-X SFP transceiver in the ethernet 1/0/1. The following command
congurationisrequired:
Switch#cong
Switch(cong)#interface ethernet 1/0/1
Switch(cong-if-ethernet1/0/1)#media-type ber-1g
Figure 4-6 Setting 1000BASE-FX Screen
4.4 SavingtheConguration
In Managed Switch, the running conguration le stores in the RAM. In the
current version, the running conguration sequence running-cong can
be saved from the RAM to FLASH by write command, so that the running
conguration sequence becomes the start-up conguration le, which is called
congurationsave.
Switch#write
Conrmtooverwritecurrentstartup-congconguration[Y/N]:y
Writerunning-congtocurrentstartup-congsuccessful
Switch#%May2200:02:57.7302023Writecongurationsuccessfully!
Figure 4-7 Write Screen
