- 16 -
Trimmer Operation
Trimmer Operating Position
Before using the Trimmer, check the following:
[Except for model B20,B21]
1. The operator must be wearing the shoulder hanging strap or shoulder
harness attached to the Trimmer, and the Trimmer should be on operator’s
right side.
[Model B20, B21, L20, L23, L26, L30, L45]
2. The operator’s right hand should be holding the shaft grip, with his or
her fingers on the throttle trigger. The right arm should be slightly bent.
3. The left hand should be holding the loop handle with the fingers
and thumb fully enclosed around the grip. The left arm should be
extended. Reposition the loop handle up or down the driveshaft if
necessary for a comfortable position.
[Model BC26, BC30, BC45, BC50]
2. The operator’s right hand should be holding the right-hand horn handle
grip, with the fingers on the throttle trigger.
3. The left hand should be holding the left-hand horn handle grip with
the fingers and thumb fully enclosed around the grip.
[All models]
4. The Trimmer weight should be evenly distributed between the arms.
The trimmer head should be near and parallel to the ground.
5. Accelerate and hold the engine at cutting speed before entering the
material to be cut.
6. Always release the throttle trigger and allow the engine to
return to idle speed when not cutting.
7. Stop the Trimmer engine when moving between work sites.
・
If the trimmer head becomes jammed, stop the engine immediately.
・
Make certain all moving parts have stopped and disconnect the
spark plug before inspecting the equipment for damage.
・
Never use a String Trimmer that has a chipped, cracked or
broken trimmer head.
[Except for model B20, B21]
IMPORTANT:
To detach the shoulder harness/ Strap quickly
from the Trimmer, pull upward on the Tab.
